CARGOMAX goods lift

The cost-effective goods lift with a capacity of up to 1000 kg - platform or cabin version.

Transporting loads of up to 1000 kg efficiently and conveniently

SIMPLE, VERSATILE, AND WITH AN ACCOMPANYING PERSON

Transporting loads of up to 1,000 kg at the push of a button - the CARGOMAX makes it easy for you. Thanks to a particularly ingenious design combined with the latest drive technology, the CARGOMAX is the first choice in efficient load transport for a wide range of applications. The CARGOMAX is also available as a goods lift with passenger. Regardless of whether it is for industry and commerce or public facilities and institutions - the CARGOMAX is simple and cost-effective.

Do you have questions? We're here to help.

0 800 / 85 85 55

Request now without obligation

Good to know you can rely on it

FLEXIBLE DESIGN

Despite the use of the latest technologies, this goods lift offers a very good price-performance ratio. The ingenious design of the CARGOMAX  allows a high degree of flexibility because it meets your requirements in terms of size, operation and design.



FUTURE-ORIENTED

Thanks to its state-of-the-art drive technology and energy efficiency, the CARGOMAX is the most economical goods lift in its category. Using high-quality components and materials also makes the CARGOMAX a durable and reliable companion.

Never take the long way round again
The CARGOMAX with passenger

The CARGOMAX WITH PASSENGER ensures you will never have to take the long way round again: efficient goods handling with an accompanying person

The advantage of a transporting goods with a passenger lies in the cost savings due to saving time and personnel costs. Loads can now be transported quickly and easily by just one person without taking the long way round.


The following type-approved versions are available:

  • CARGOMAX KB
    Goods lift with cabin and passenger

  • CARGOMAX KSB/KFB
    Goods lift with sliding/folding door and passenger

Design and specifications

Depending on the location, the lift well can be built in

  • Concrete
  • Brick
  • Wood
  • Steel or aluminium

Walls:
Electrolytically galvanised sheet steel, or stainless, steel or your choice of RAL colour

Floor:
Checker plate or synthetic coating

Loading:
Through loading or corner loading

Selection of ram protection fenders

Load capacity:
up to 1,000 kg

Single hinged doors, primed, with mechanical or electrical door interlock and door contact;
doors according to EN81-58 E120 available

  • Call and send control with automatic stop
  • Backpack suspension with energy-saving electromechanical drive system
  • 2 roller chains designed with 12-fold safety factor
  • Precision safety brake
  • Travel speed monitoring device that switches off the system and triggers the safety brake if the normal travel speed is exceeded
  • Door interlocks incl. fail safe door system
  • Overload protection
  • Emergency stop button
  • Door zone monitoring, etc.

Lift well pit:
150 mm


Lift well head:
for platform version 2150 mm
for cabin version: 2450 mm


Load capacity:
for platform version 400 kg (max. 2 m┬▓ cabin area)
for cabin version 500 kg (max. 2,5 m┬▓) or 1000 kg
